GF27.60-D-3017H Control Valve Pressure, Function

GF27.60-D-3017H Control Valve Pressure, Function
- TRANSMISSION 722.6


The control valve pressure is regulated at the control valve pressure regulating valve, dependent on the working pressure, up to a maximum pressure of 8 bar. It supplies the modulating pressure control solenoid valve (Y3/6y1), the shift pressure control solenoid valve (Y3/6y2) and shift valve pressure regulating valve.
