GF27.10-D-3023H Function of Shift Lock Override

GF27.10-D-3023H Function of Shift Lock Override
- TRANSMISSION 722.6






65 Selector lever
95 Release button

If it is not possible to engage a drive position from selector lever position "P" due to a mechanical or electrical/electronic fault, the selector lever position "P" lock can be released using the shift lock override function.

To do this, a cover under the selector lever must be removed and the release button under it pressed using a suitable tool. The selector lever position "P" lock is released via a bolt in the lock solenoid valve. The selector lever can be shifted out of selector lever position "P" when the release button is operated simultaneously.
