AR32.20-D-0200H Remove/Install Front Spring

AR32.20-D-0200H Remove/Install Front Spring






1 Bolts
2 Spring clamp plates
3 Front spring











7 Torsion bar linkage
8 Stop plate
9 Reinforcement plate (with code ZG1, 8 Stop plate ZG2, ZG3, ZG4 All- wheel drive)
10 Transverse control arms
11 Link rod (with code LG0, LG1, Bi- xenon headlamp)
