GF32.33-D-3010H Electronic Level Control (ELC (ENR)) Pressure Supply Function

GF32.33-D-3010H Electronic Level Control (ELC [ENR]) Pressure Supply Function


- with CODE (CE2) Rear air suspension

General

In normal driving mode, the electronic level control (ELC) system operates with a pressure between 6 bar and 10 bar, depending on the load. The air compressor motor (A9/1m1) is used to supply pressure to the air spring bellows. This motor is integrated, together with the air compressor pressure relief valve (A9/1y1), into the level control compressor (A9/1).

Following repeated raising or lowering of the vehicle rear axle, the level control compressor is deactivated in order to protect the ELC system.
