Alternator Pulley / Clutch: Service and Repair

AR15.40-D-5710SD Remove/Install Alternator Belt Pulley







1 Alternator shaft
2 Belt pulley
3 Socket wrench
4 Cap

G2/2 Alternator (with engine 646.989/990)
G2/7 AC alternator with LIN bus (for engine 642, 646.984/985/986, 651)
G2/8 Alternator (with engine 271)











601 589 00 10 00
Screwdriver bit





602 589 00 10 00
Socket wrench
