AR14.40-D-2041S Check Adblue(R) Concentration

AR14.40-D-2041S Check AdBlue(R) Concentration






1 Prism
2 Hinged lid
3 Adjustment screw
4 Eyepiece
5 Hand-held refractometer, BLUETEC

B AdBlue(R) scale








Shown vehicle without code (KP2) AdBlue tank, 12 l, in engine compartment

6 AdBlue(R) filler neck
7 Cap
8 AdBlue(R) tank
9 Drain hose (for vehicles without code (KP2) AdBlue tank, 12 l, in engine compartment)
10 Plug (for vehicles without code (KP2) AdBlue tank, 12 l, in engine compartment)
