GF83.70-D-2010HF Teach In STH Radio Remote Control, Function

GF83.70-D-2010HF Teach In STH Radio Remote Control, Function
MODEL 906.111 /113 /131 /133 /135 /153 /155 /211 /213 /231 /233 /235 /253 /255 /611 /613 /631 /633 /635 /637 /653 /655 /657 /711 /713 /731 /733 /735
- with CODE (H12) Warm water auxiliary heater
- with CODE (HY1) Radio remote control for auxiliary heater
- Stationary heater (STH)

MODEL 906.611 /613 /631 /633 /635 /637 /653 /655 /657 /711 /713 /731 /733 /735
- with CODE (HZ5) 10 kW warm water auxiliary heater with timer
- with CODE (HY1) Radio remote control for auxiliary heater
- Stationary heater (STH)

To be able to activate the stationary heater (STH) system via the STH radio remote control (FFB) and thus activate heater operation of the stationary heater unit, it is necessary to teach in the STH FFB.
The teach-in procedure for the STH FFB is as follows:
- Press the warm water stationary heater switch (S46/11) in the upper subfield and hold depressed for t = 10 s. The warm water auxiliary heating control unit (N33/3) reads in the signal of the warm water stationary heater switch and permanently actuates the red light emitting diode (LED) in the warm water stationary heater switch , but heater operation of the stationary heater unit is not activated.
- After elapse of the 10 s, the red LED in the warm water stationary heater switch flashes and the teach-in process can be started.
- Release the warm water stationary heater switch again within t = 3 s. The red LED in the warm water stationary heater switch continues flashing, but heater operation of the stationary heater unit is not activated.
- Press the "On" button or the "Off" button on the STH FFB within t = 3 s (teach-in process begins).
When the "On" button is pressed, the transmitter identifier of the STH FFB is added to the transmitter memory (EEPROM) in the stationary heater radio signal receiver (A49/4).
When the "Off" button is pressed, only the transmitter identifier of the STH FFB used is stored in the stationary heater radio signal receiver, all other stored transmitter identifiers will be deleted.

- After successful completion of the teach-in process, the STH FFB transmits a short pulse (radio signal) to the stationary heater radio signal receiver. The warm water auxiliary heating control unit reads in this pulse (radio signal) and interrupts actuation of the red LED in the warm water stationary heater switch via a discrete line.

If the particular time windows are not observed, the STH system is reset to its original state. The stationary heater unit will not start. The teach-in or switch-on procedure can be repeated.

You can teach in a maximum of 4 STH FFB units in the "EEPROM" of the stationary heater radio signal receiver.
