Fan Shroud: Service and Repair

AR20.40-D-6800SF Remove/Install Fan Shroud






Shown for engine 642.992

1 Fan shroud
2 Cover
3 Coolant hose (on engine 642)
4 Catch hook
5 Guide
6 Guide (on engine 642)
7 Screw
8 Counterholder
9 Fan drive (on engine 642)
10 Viscous fan clutch
11 Open end wrench





Only on engine 642.896/898 with code (HH9) Regulated air conditioning (Tempmatic)

10 Viscous fan clutch
12 Electrical line
13 Screw
14 Electrical connector
15 Screw
16 Torque support











906 589 00 40 00
Counterholder
