GF72.29-D-2012HD Actuate Electric Load Component Sliding Door (E-LST), Function
GF72.29-D-2012HD Actuate Electric Load Component Sliding Door (E-LST), Function
- with CODE (T55) Electrical actuation for right sliding door Sliding door OBF switch
- with CODE (T56) Electrical actuation for left sliding door Sliding door OBF switch
Function requirements for opening:
- No overvoltage or undervoltage
- Left sliding door button (N72/1s1) or right sliding door button (N72/1s11) actuated once at bottom
Opening sequence:
- Right sliding door control unit (N69/6) or left sliding door control unit (N69/7) transmit to opening assist
- signal "Open E-LST lock"
- E-LST lock to right sliding door control unit or left sliding door control unit
- signal "Lock actuated" of right sliding door CL rotary tumbler switch (M14/27s1) or left sliding door CL rotary tumbler switch (M14/28s1)
- Right sliding door control unit or left sliding door control unit to right sliding door drive (M73/1) or left sliding door drive (M73/2)
- The right sliding door drive or left sliding door drive moves the E-LST in the "E-LST open" position
The anti-pinch protection is active during the complete opening path.
Actuation of left sliding door button or right sliding door button on right bottom when "Open" function is active
When reactuated, the E-LST stops.
If the left sliding door button or right sliding door button is reactuated, the E-LST moves to the "Open" direction.
Actuation of left sliding door button or right sliding door button at top when "Open" function is active
When actuated, the E-LST is stopped.
If the left sliding door button or right sliding door button at top is reactuated, the E-LST moves to the "Close" direction.
Function requirements for closing:
- No overvoltage or undervoltage
- Left sliding door button or right sliding door button actuated once at top
Closing sequence:
- Right sliding door control unit or left sliding door control unit transmit to right sliding door drive or left sliding door drive
- The right sliding door drive or left sliding door drive moves the E-LST in the "E-LST closed" position
- E-LST lock to right sliding door control unit or left sliding door control unit
- signal "Door closed" of right sliding door CL rotary tumbler switch or left sliding door CL rotary tumbler switch to right sliding door control unit or to left sliding door control unit
The anti-pinch protection is active up to the pre-locking position.
Actuation of left sliding door button or right sliding door button at top when "Close" function is active
When reactuated, the E-LST stops.
If the right sliding door button or left sliding door button is reactuated, the E-LST moves to the "Close" direction.
Actuation of left sliding door button or right sliding door button at bottom when "Close" function is active
When actuated, the E-LST is stopped.
If the left sliding door button or right sliding door button is reactuated, the E-LST moves to the "Open" direction.
