GF54.65-D-2005H Back-In Parking, Function

GF54.65-D-2005H Back-In Parking, Function

- with CODE (FR7) Backup assist preinstallation

Reverse parking
The driver is visually assisted in all maneuvering situations in which backing up or back-in parking is required.

Function requirements
- Circuit 15 ON
- Reverse gear engaged
- Trunk lid closed

System start
Once the driver has brought the vehicle to the start position, he/she starts the backup camera system (RFK) by engaging reverse gear. A current image of the area to the rear of the vehicle is displayed to the driver on the display of the radio/radio with navigation (N87/1) or on the backup camera monitor (A96).
