GF72.29-D-3010H Power Windows Convenience Opening Via Air Recirculation Mode Button, Function

GF72.29-D-3010H Power Windows Convenience Opening Via Air Recirculation Mode Button, Function

- except CODE (ZU7) National version for Canada
- except CODE (ZU8) National version for USA

Function requirements:
- "Circuit. 15 ON"
- No overvoltage or undervoltage
- Windows normalized
- Previous convenience closing via air recirculation mode button (S98s6)

Function interruption (for all windows):
- Actuation request is rescinded
- Failure of controller area network bus, class B (interior compartment) (CAN-B) message

Function interruption (for individual windows):
- Actuate driver power window button (S47s1) or front passenger power window button (S47s2) in any direction
- Actuate front passenger power window switch (S21/2) in any direction
- Blockage detection
- The function requirements are no longer fulfilled

Open window via "Recirculated air" function

By pressing the air recirculation mode button the AAC control and operating unit (S98) for > 1.5 s, the windows can be opened to the previous position via the air recirculation button after previous comfort closing. The actuation request is relayed via CAN-B to the driver door control unit (N69/1) and SAM control unit (N10), which then actuates the driver door power window motor (M10/1) and front passenger door power window motor (M10/2).

The front windows open up to the stored position, if the current window position is at least 8 Hall pulses above the stored opening position. A window will not be activated if it is positioned less than 8 Hall pulses above the stored opening position, or if it has in the meantime been lowered to below the stored position.

The rear vent window, with code (W32) Rear power vent windows in passenger compartment, can be opened via the "Recirculated air" function.

If "Closing" via the air recirculation mode button is initiated again during the "Opening" sequence before the stored position is reached, then the initially stored opening position is retained. The motion is reversed immediately.
