AR26.45-D-0070-01A Remove/Install Output Flange of Output Shaft

AR26.45-D-0070-01A Remove/Install Output Flange of Output Shaft
- TRANSMISSION 711.651
- with CODE (N07) Power take-off countershaft (2b) with flange
- TRANSMISSION 711.660
- with CODE (N07) Power take-off countershaft (2b) with flange









901 589 00 07 00
Pin wrench





000 589 65 33 00
Puller





Shown on transmission 711.680

1 Counterhold the output flange (1) with the pin wrench and unscrew bolt (3).
2 Remove washer (2).
3 Remove output flange (1) using puller.
4 Install in the reverse order.
