AR41.10-D-0101-03HA Press on Propeller Shaft Center Support Bearing

AR41.10-D-0101-03HA Press on Propeller Shaft Center Support Bearing
- Front propeller shaft intermediate bearing








906 589 00 15 00
Drift





906 589 02 15 00
Drift





711 589 01 15 00
Drift





Perform following operation step only for propeller shaft center support bearing version with protective caps.

1 Drive protective cap (4) using drift 906 589 00 15 00 onto universal joint (8) of front propeller shaft.

Note installation position of protective cap (4).





2 Drive propeller shaft center support bearing (3) using drift 711 589 01 15 00 flush onto universal joint (8) of front propeller shaft.

Make sure when removing a propeller shaft center support bearing with shim (7) that the new propeller shaft center support bearing is also installed with a shim. If this is not observed humming, droning and starting noise may be heard.





Perform the following two steps only for the propeller shaft center support bearing version with protective caps, if the protective cap (6) was removed.

3 Clamp propeller shaft onto rigid part of universal joint in vise.

4 Drive protective cap (6) using drift 906 589 02 15 00 up to end stop on propeller shaft (7).

Note installation position of protective cap (6).
