GF27.60-D-3018H Shift Valve Pressure, Function

GF27.60-D-3018H Shift Valve Pressure, Function
- TRANSMISSION 722.6


The shift valve pressure is derived from the control valve pressure, is regulated at the shift valve pressure regulating valve and is then applied to the following components:
^ 1-2 and 4-5 shift solenoid valve (Y3/6y3)
^ 3-4 shift solenoid valve (Y3/6y4)
^ 2-3 shift solenoid valve (Y3/6y5)
^ Torque converter lockup PWM solenoid valve (Y3/6y6)
^ 3-4 and 2-3 shift pressure shift valve

The shift valve pressure controls the command valves via the upshift/downshift solenoid valves.
