AR91.40-D-1030-01A Detach/Attach Seat Belt At Seat

AR91.40-D-1030-01A Detach/Attach Seat Belt At Seat












1. Remove cover of bolt (1).
2. Remove bolt (1) at seat (3).
3. Partially pull out side panel in area of bolt (1) and remove seat belt.
4. Install in the reverse order.
