GF00.20-D-2010HL Display Service Scope, Function

GF00.20-D-2010HL Display Service Scope, Function

- except CODE (JK3) High-end instrument cluster with speedometer in km

General
The Service A or B to be performed appears in addition to the service displays. The remaining distance in kilometers or the remaining time in days up to Service A or B can be shown on the display (A1p1) of the instrument cluster (A1). To this end, the respective service symbol is shown, one wrench for Service A, and 2 wrenches for Service B.

Every Service A is always followed by Service B. This computation is made automatically in the instrument cluster. In the service sheet, the displayed service A or B can be processed without calculation of the path.

The particular service scope is shown on the instrument cluster display after one of the following procedures:
- Service indicator can be called up by driver
- Automatic service indicator

Service indicator can be called up by driver
The service indicator can be activated by the driver using the M button, reset button (A1s2), the plus button (A1s3) and the minus button (A1s4) on the instrument cluster:
- Status "circuit 15R ON" is activated.
- Press the M button repeatedly until the service symbol and the current remaining distance, the remaining time or service exceeded is shown on the instrument cluster display. The plus button or minus button can be used to switch between the remaining distance and the remaining time.

Automatic service indicator
The automatic service indicator is activated when one of the following conditions is met:
- 5 s after status "circuit 15 ON" or "circuit 61 ON" was activated.
- The warning threshold for the remaining time has been reached.
- The warning threshold for the remaining distance has been exceeded.
