GF83.70-D-2011H Stationary Heater (STH) Operating Time, Function

GF83.70-D-2011H Stationary Heater (STH) Operating Time, Function
MODEL 906.111 /113 /131 /133 /135 /153 /155 /211 /213 /231 /233 /235 /253 /255 /611 /613 /631 /633 /635 /637 /653 /655 /657 /711 /713 /731 /733 /735 as of 1.9.08
- with CODE (H12) Auxiliary heater (warm water)
- with CODE (HY1) Radio remote control for auxiliary heater

MODEL 906.611 /613 /631 /633 /635 /637 /653 /655 /657 /711 /713 /731 /733 /735 as of 1.9.08
- with CODE (HZ5) 10kW warm water auxiliary heater with timer
- with CODE (HY1) Radio remote control for auxiliary heater

Change operating time via the stationary heater (STH) radio remote control (RRC [FFB]) for auxiliary heater With the RRC [FFB] switched on and the red light-emitting diode (LED) flashing on the STH RRC [FFB], press the activate button and the OK button simultaneously. The LED on the STH RRC [FFB] illuminates in green. Now press the activate button repeatedly until the required operating time is displayed.
The following intervals can be set:
- 20 min: the LED of the STH RRC [FFB] flashes twice in green.
- 30 min: the LED of the STH RRC [FFB] flashes three times in green.
- 40 min: the LED of the STH RRC [FFB] flashes four times in green.
- 60 min: the LED of the STH RRC [FFB] flashes six times in green.

Once the operating time has been selected, the OK button must be pressed. The LED illuminates in red for the duration of the data transfer. If the LED performs 2 long green flashes, the selected operating time has been saved. If no settings have been made, the LED flashes 6 times and the STH RRC [FFB] goes into the idle state.
