Home >> Mercedes Benz Truck >> 2010 >> Sprinter 3500 Cab (906.155) V6-3.0L DSL Turbo (642.898) >> Repair and Diagnosis >> Engine, Cooling and Exhaust >> Cooling System >> Coolant >> Service and Repair >> Removal and Replacement >> AP20.00-D-2080H Replace Coolant

AP20.00-D-2080H Replace Coolant




AP20.00-D-2080H Replace Coolant









Shown on engine 646

1 Cap
2 Drain plug on radiator
