AR42.10-D-0010-02H Carrying Out Bleeding Operation

AR42.10-D-0010-02H Carrying Out Bleeding Operation














001 589 72 21 00
Torque wrench

1 Open right rear vent valve (1), if brake fluid flows out free of bubbles, close the right rear vent valve (1).
2 Open left front vent valve (2), if brake fluid flows out free of bubbles, close left front vent valve (2).
3 Open left rear vent valve (3), if brake fluid flows out free of bubbles, close left rear vent valve (3).
4 Open right front vent valve (4), if brake fluid flows out free of bubbles, close right front vent valve (4).
