GF77.20-D-0005H Tilting/Sliding Roof (SR), Function

GF77.20-D-0005H Tilting/Sliding Roof (SR), Function

- with CODE (D27) Power glass tilting/sliding roof

Function requirements:
- Circuit 15R ON
- Front tilting/sliding roof (M12) normalized
- No overvoltage or undervoltage
Overvoltage is present when voltage > 16.5 V. Undervoltage is present when voltage < 9 V.
Only the manual functions for the front tilting/sliding roof are available in the denormalized state.

The front tilting/sliding roof is a combination of tilting/sliding roof.The sliding roof opens to the rear. The tilting roof opens upward at the rear.

The "Open/close sliding roof" function or the "Open/close tilting roof" function can only be performed separately.

It is operated via the tilting/sliding roof control button (N70s1) integrated into the DBE control unit (N70) The DBE control unit (N70) accomplishes the desired operation by actuating the corresponding front tilting/sliding roof motor (M12m1).

The "Convenience feature" function is actuated via the transmitter key.

The sliding roof is in the closed position at the front stop and in the end position at the rear stop.

In the closed position, the tilting roof is located at the front stop, in the tilting position (ventilation position) it is located at a defined position between the front and rear stops.

The front tilting/sliding roof is equipped with an excess force limiter and an obstruction sensor unit.

The following functions can be actuated with the tilting/sliding roof control button:
- "Manually CLOSE" sliding roof is actuated by the "Close sliding roof" command by pressing the tilting/sliding roof control button toward the front up to the pressure point.
- "Automatically CLOSE" sliding roof is actuated by the "One-touch close sliding roof" command by pressing the tilting/sliding roof control button toward the front beyond the pressure point
- "Manually OPEN" sliding roof is actuated by the "Open sliding roof" command by pulling the tilting/sliding roof control button toward the rear up to the pressure point.
- "Automatically OPEN" sliding roof is actuated by the "One-touch open sliding roof" command by pulling the tilting/sliding roof control button toward the rear beyond the pressure point.
- "Manually CLOSE" tilting roof is actuated by the "Close tilting roof" command by pulling the tilting/sliding roof control button downward up to the pressure point.
- "Automatically CLOSE" tilting roof is actuated by the "One- touch close tilting roof" command by pulling the tilting/sliding roof control button downward beyond the pressure point
- "Manually OPEN" tilting roof is actuated by the "Open tilting roof" command by pressing the tilting/sliding roof control button upward up to the pressure point.
- "Automatically OPEN" tilting roof is actuated by the "One-touch open tilting roof" command by pressing the tilting/sliding roof control button upward beyond the pressure point.
