GF88.79-P-0005GZ Electrically Adjustable Outside Mirrors, Function

GF88.79-P-0005GZ Electrically adjustable outside mirrors, function
- 164.1/8 up to Model year 8

Entire function
With the left outside mirror adjustment selection switch (S20/1s10) or right outside mirror adjustment selection switch (S20/1s11), the left electrically adjustable and heated outside mirror (M21/1) or right electrically adjustable and heated outside mirror (M21/2) can be selected for manual adjustment. The mirror lens can be moved to the desired position with the outside mirror adjustment rocker switch (S20/1s12) An LED in the corresponding right/left outside mirror preselection switch indicates which outside mirror can be adjusted at this moment.

Partial functions
- Horizontal and vertical mirror lens adjustment
- Mirror selection between left outside mirror and right outside mirror
- Automatically dimming driver's side outside mirror and inside rearview mirror
- Move left outside mirror and right outside mirror to garage position (with folding left/right outside mirror, code 500)

The mirror heater is automatically regulated when the vehicle engine is running depending on the outdoor temperature and dewpoint. The left outside mirror and right outside mirror can be folded in and out via the outside mirror fold-in/fold-out switch (S20/1s9) (with folding left/right outside mirror, code 500).

- Store, call and automatically adjust position of left outside mirror and right outside mirror with the memory function
(with memory package (driver seat, steering column, mirror), code 275)
- Move right outside mirror to park position (with memory package (driver seat, steering column, mirror), code 275)
