GF80.20-P-3009RT Lock/Unlock Vehicle With Interior Switch, Function

GF80.20-P-3009RT Lock/unlock Vehicle With Interior Switch, Function

Function
The signals from the left interior CL switch (S85/5) and right interior CL switch (S85/6) are read in by the door control units and transmitted to the Controller Area Network bus, class B (passenger compartment) (CAN B)
The EIS control unit (N73) reads in the signals and actuates the locking and locking the central locking (CL) depending on the:
^ Status of CL,
^ Door status (signals of rotary tumbler switch in CL motors via CAN B)

Fuel filler flap remains unlocked when locking with the interior CL switch.

The following situations are possible:

Driver door open.
^ All doors, except the driver door, are locked.
^ Fuel filler flap remains open

Passenger door or driver and passenger door open:
^ Locking disabled

Locking from outside with transmitter key (A8/1):
^ Only locking allowed

Unlocking from outside with transmitter key:
^ If no door is open, full function.
