GF80.50-P-2003RT Deactivate Anti-Theft Alarm System, Function

GF80.50-P-2003RT Deactivate Anti-Theft Alarm System, Function
- with CODE (551) Anti-theft alarm system (ATA [EDW])


Deactivating anti-theft alarm system (ATA)
^ Unlock central locking (CL) with transmitter key (A8/1) or
^ Insert transmitter key into EIS control module (N73) or
^ Unlock via Keyless Go (KG) (with Keyless Go, code 889)

The corresponding signals for the EIS control module are read in via the controller area network bus, class B (interior compartment (CAN B) by the rear SAM control module (N10/8) The rear SAM control module deactivates the ATA.
