System Description

HORN: HORN SYSTEM: SYSTEM DESCRIPTION

1. HORN SYSTEM DESCRIPTION

When the steering pad (horn button) is pressed, a signal is sent from the steering pad through the steering pad switch assembly with modulator (steering pad ECU) to the spiral cable. The spiral cable and front light ECU (front controller) communicate via the CAN line. The front light ECU receives the signal and sends it to the vehicle horns, causing the horns to sound.

2. FUNCTION OF MAIN COMPONENT
