Audible Warning Device: Testing and Inspection

BRAKE CONTROL: SKID CONTROL BUZZER: INSPECTION

1. CHECK SKID CONTROL BUZZER ASSEMBLY

(a) Apply negative battery voltage to terminal 1, and positive battery voltage to terminal 2 of the skid control buzzer, and then check that the buzzer sounds.





OK:

Skid control buzzer sounds.

If the result is not as specified, replace the skid control buzzer assembly.
