C1428

BRAKE CONTROL: VEHICLE STABILITY CONTROL SYSTEM: C1428: Motor Circuit Malfunction
C1428 - Motor Circuit Malfunction

DESCRIPTION





WIRING DIAGRAM

Refer to DTCs C0273, C0274 and C1361 C0273.

INSPECTION PROCEDURE

NOTICE:
When replacing the brake actuator assembly, perform zero point calibration and store system information Programming and Relearning.

PROCEDURE

1. REPLACE BRAKE ACTUATOR ASSEMBLY

(a) Replace the brake actuator assembly Removal.

NEXT -- END
