C1428

BRAKE CONTROL: VEHICLE STABILITY CONTROL SYSTEM: C1428: Motor Circuit Malfunction
C1428 - Motor Circuit Malfunction

DESCRIPTION





WIRING DIAGRAM

Refer to DTCs C0273, C0274 and C1361 C0273.

INSPECTION PROCEDURE

NOTICE:
When replacing the brake actuator assembly, perform zero point calibration and store system information Calibration.

PROCEDURE

1. REPLACE BRAKE ACTUATOR ASSEMBLY

(a) Replace the brake actuator assembly Removal.

NEXT -- END
