Installation

CELLULAR COMMUNICATION: TELEPHONE MICROPHONE: INSTALLATION

1. INSTALL MICROPHONE ASSEMBLY





(a) Attach the 2 claws to install the microphone.

(b) Connect the connector.





(c) Install the cover and plate with the 9 screws.

2. INSTALL GARAGE DOOR OPENER TRANSMITTER





(a) Connect the connector and install the amplifier, as shown in the illustration.

(b) Install the 2 screws.

3. INSTALL MAP LIGHT ASSEMBLY

(a) for Standard Body:

Install the map light Installation.

(b) for Long Body:

Install the map light Installation.
