Inspection

AA80F AUTOMATIC TRANSMISSION: SHIFT LOCK SYSTEM: INSPECTION

INSPECTION

1. INSPECT SHIFT LOCK SOLENOID





(a) Measure the resistance according to the value(s) in the table below.
HINT: Disconnect the solenoid connector.

Standard Resistance:





If the result is not as specified, replace the transmission floor shift assembly.





(b) Measure the resistance according to the value(s) in the table below.
HINT: Disconnect the solenoid connector.

Standard Resistance:





If the result is not as specified, replace the transmission floor shift assembly.
