Installation

AUDIO / VISUAL: AUDIO AND REAR AIR CONDITIONER CONTROL SWITCH (for Power Seat): INSTALLATION

INSTALLATION





1. INSTALL REAR POWER SEAT MODULE SWITCH
(a) Install the radio switch and volume with the 4 screws.
2. INSTALL NO. 1 REAR SEAT CENTER ARMREST PANEL Reassembly
3. INSTALL REAR SEAT CENTER ARMREST ASSEMBLY Reassembly
4. INSTALL REAR SEATBACK ASSEMBLY CENTER Installation
5. INSTALL REAR SEAT CUSHION ASSEMBLY CENTER Installation
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. INSTALL COWL TOP VENTILATOR LOUVER RH Installation
8. PERFORM INITIALIZATION
(a) Perform initialization Repair Instruction - Initialization.
NOTE:
Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
