C1567

POWER STEERING: POWER STEERING SYSTEM: C1567: Lost Communication between EPS ECU and VGRS ECU

DTC C1567 - Lost Communication between EPS ECU and VGRS ECU

DESCRIPTION

Based on the steering sensor's signal, the power steering ECU determines if the correct type of steering angle sensor is installed.






INSPECTION PROCEDURE

PROCEDURE

1. CHECK STEERING ANGLE SENSOR
(a) Check if a steering angle sensor that complies with the vehicle's specifications is installed.
OK:
Steering sensor that complies with vehicle's specifications is installed.
NG -- REPLACE STEERING ANGLE SENSOR
OK -- REPLACE POWER STEERING ECU
