Removal

BRAKE: FRONT BRAKE (for 4GR-FSE): REMOVAL

REMOVAL
HINT:
- Use the same procedures for the RH side and LH side.
- The procedures listed below are for the LH side.

1. REMOVE FRONT WHEEL
2. DRAIN BRAKE FLUID
NOTE:
If brake fluid leaks onto any painted surface, wash off or remove the brake fluid completely.

3. REMOVE FRONT DISC BRAKE CYLINDER ASSEMBLY





(a) Remove the union bolt and gasket from the disc brake cylinder assembly, then disconnect the flexible hose.





(b) Remove the 2 bolts and disc brake cylinder assembly.
