Removal

GARAGE DOOR OPENER: GARAGE DOOR OPENER SWITCH:

REMOVAL

1. REMOVE ROOF CONSOLE BOX ASSEMBLY





(a) Using a screwdriver, disengage the 2 claws and open the 2 covers.
- Tape the screwdriver tip before use.





(b) Remove the 2 screws.





(c) Using a moulding remover, disengage the 2 clips.
(d) Disconnect the connectors and remove the roof console box assembly.
