Steering Wheel Vibrates or Abnormal Noise Is Heard From Steering Wheel

Steering Wheel Vibrates or Abnormal Noise is Heard from Steering Wheel

INSPECTION PROCEDURE

HINT: Check that no DTC is output for the VGRS system and electronically controlled brake system.

Steps 1-2:
