Removal and Replacement

Integration Control And Panel:

INTEGRATION CONTROL AND PANEL

REMOVAL

1. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission)
2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission)
3. REMOVE UPPER NO.1 CONSOLE PANEL GARNISH (for Automatic Transmission)
4. REMOVE UPPER NO.2 CONSOLE PANEL GARNISH (for Automatic Transmission)
5. REMOVE CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission)
6. REMOVE REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission)
7. REMOVE FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission)
8. REMOVE FRONT ASH RECEPTACLE SUB-ASSEMBLY
9. REMOVE CONSOLE BOX REGISTER ASSEMBLY
10. REMOVE CONSOLE BOX
11. REMOVE NO.3 INSTRUMENT PANEL REGISTER ASSEMBLY
12. REMOVE CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL
13. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY
14. REMOVE TIRE PRESSURE MONITOR RECEIVER ASSEMBLY
15. REMOVE NO.1 RADIO BRACKET
16. REMOVE NO.2 RADIO BRACKET
17. REMOVE RADIO RECEIVER ASSEMBLY

INSTALLATION

1. INSTALL RADIO RECEIVER ASSEMBLY
2. INSTALL NO.2 RADIO BRACKET
3. INSTALL NO.1 RADIO BRACKET
4. REMOVE TIRE PRESSURE MONITOR RECEIVER ASSEMBLY
5. INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY
6. INSTALL CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL
7. INSTALL NO.3 INSTRUMENT PANEL REGISTER ASSEMBLY
8. INSTALL CONSOLE BOX
9. INSTALL CONSOLE BOX REGISTER ASSEMBLY
10. INSTALL FRONT ASH RECEPTACLE SUB-ASSEMBLY
11. INSTALL FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission)
12. INSTALL REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission)
13. INSTALL CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission)
14. INSTALL UPPER NO.2 CONSOLE PANEL GARNISH (for Automatic Transmission)
15. INSTALL UPPER NO.1 CONSOLE PANEL GARNISH (for Automatic Transmission)
16. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission)
17. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission)
