Removal and Replacement

Back Door Courtesy Switch:

BACK DOOR COURTESY SWITCH

REMOVAL

1. REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP
2. REMOVE LUGGAGE LOCK CONTROL CABLE PLATE
3. REMOVE LUGGAGE COMPARTMENT DOOR INSIDE HANDLE
4. REMOVE LUGGAGE COMPARTMENT DOOR COVER
5. REMOVE LUGGAGE COMPARTMENT DOOR REINFORCEMENT
6. REMOVE LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY
7. REMOVE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY

INSTALLATION

1. INSTALL LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY
2. INSTALL LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY
3. INSTALL LUGGAGE COMPARTMENT DOOR REINFORCEMENT
4. INSTALL LUGGAGE COMPARTMENT DOOR COVER
5. INSTALL LUGGAGE COMPARTMENT DOOR INSIDE HANDLE
6. INSTALL LUGGAGE LOCK CONTROL CABLE PLATE
7. INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP
