Tilt and Telescopic Manual Switch Circuit

Tilt and Telescopic Manual Switch Circuit

DESCRIPTION
The signals generated by operating the manual switch are sent to the multiplex tilt & telescopic ECU through the communication bus.

INSPECTION PROCEDURE

Step 1:
