Auto Up Operation Does Not Fully Close Power Window (Jam Protection Function Is Activated)

AUTO UP OPERATION DOES NOT FULLY CLOSE POWER WINDOW (JAM PROTECTION FUNCTION IS ACTIVATED)

HINT: This symptom may occur to the right or left door windows.

CIRCUIT DESCRIPTION

If the door glass or the power window regulator motor does not operate smoothly, the jam protection function may trigger automatically, resulting in the AUTO UP function being unable to fully close the window.
