Low Tire Pressure Indicator: Description and Operation

Low Tire Pressure Warning Light






This light comes on when the engine switch is selected in "IG-ON" mode. If the tire pressure warning system works properly and tire inflation pressure is appropriate, the light goes off after a few seconds.

This light comes on or flashes in the following cases when the engine switch is selected in "IG-ON" mode:

- When the low tire inflation pressure is detected while driving - If any tire has low inflation pressure, the light comes on. The light goes off after the tire inflation pressure is adjusted to a specified level.

- When initializing the system - If initialization is completed, the light blinks three times.

- When the system malfunctions - If the system malfunctions, the light blinks.
