Luggage Compartment Door Lock Circuit

LUGGAGE COMPARTMENT DOOR LOCK CIRCUIT

CIRCUIT DESCRIPTION

The switch signal via the luggage door opener switch is transmitted multiply to the theft warning ECU from the driver's side J/B. Then, when the theft warning ECU recognizes the main key, the luggage room J/B drives the luggage door opening motor.
