Data List

DATA LIST

a. Connect the hand-held tester to the DLC3.
b. Turn the ignition switch to the ON position and turn the hand-held tester on.

Part 1:

Part 2:

Part 3:

c. Operate the hand-held tester according to the steps on the display and select "DATA LIST".
