Garage Door Opener Transmitter: Service and Repair

GARAGE DOOR OPENER SYSTEM

Garage Door Opener System:

REMOVAL

1. REMOVE FRONT PERSONAL LIGHT LENS

2. REMOVE FRONT PERSONAL LIGHT
a. Remove the 3 screws.
b. Disconnect the 2 connectors.

3. REMOVE GARAGE DOOR OPENER SWITCH

INSTALLATION

1. INSTALL GARAGE DOOR OPENER

2. INSTALL FRONT PERSONAL LIGHT
a. Connect the 2 connectors.
b. Install the 3 screws.

3. INSTALL FRONT PERSONAL LIGHT LENS
