Clearing Trouble Codes

CLEARING DTC's

Clear the DTC.
(1) Using SST, connect terminals TC and E1 of DLC2 or DLC1.
SST 09843-18020
(2) IG switch ON.





(3) Clear the DTC stored in ECU by depressing the brake pedal 8 or more times within 5 seconds.
(4) Check that the warning light shows the normal code.
(5) Remove the SST from the terminals of DLC2 or DLC1.
SST 09843-18020
