On-Vehicle Inspection

Part 1 Of 3:

Part 2 Of 3:

Part 3 Of 3:

FLOW-CHART
Trouble Symptom
a. Hard steering at idle or low-speed driving.
b. Steering too sensitive during high-speed driving.

Preliminary Check
a. Check tire pressure.
b. Check lubrication of the suspension and the steering linkage.
c. Check front wheel alignment.
d. Check steering system joint and suspension arm ball joint.
e. Check for bent steering column.
f. Check that all connectors are secure.
g. Check power steering pump fluid pressure.
