Activation When Disposing of Front Seat Outer Belt Pretensioner

1. Disarm SRS as described under Air Bag Disarming & Arming.
2. Remove seat belt pretensioner as described under Seat Belt Pretensioner, Service and Repair.
3. Bolt pretensioner to a discarded tire and rim, Fig. 26.

Fig. 26 Seat Belt Pretensioner Disposal Outside Vehicle:

4. Connect special deployment tool No. 09082-00700, or equivalent, to air bag electrical connector from underneath wheel.
5. Move deployment tool at least 33 feet away from wheel.
6. Connect tool to a fully charged 12 volt battery.
7. Ensure no people, animals or objects are within 33 feet of air bag.
8. Press deployment button and deploy pretensioner.
9. If pretensioner does not deploy, consult Lexus for disposal procedures.
