Home >> Lexus >> 1993 >> ES 300 V6-3.0L (3VZ-FE) >> Repair and Diagnosis >> A L L Diagnostic Trouble Codes ( DTC ) >> Testing and Inspection >> Manufacturer Code Charts >> ABS (Antilock Brake System) >> DTC 51

DTC 51

Fig. 55 Diagnostic (Trouble) Code 52, ABS Pump Motor Lock.:
