Garage Door Opener Transmitter: Service and Repair

Garage Door Opener System:






REMOVAL
REMOVE SUNVISOR
a. Remove the 2 screws.
b. Disconnect the garage door opener switch connector.

INSTALLATION
INSTALL SUNVISOR
a. Connect the garage door opener switch connector.
b. Install the screws and sun visor.
