Back Door Lock and Unlock Switch Circuit
CIRCUIT DESCRIPTIONThe back door courtesy switch goes on when back door is opened and goes off when back door is closed.
Wiring Diagram:
Step 1 - 3:
INSPECTION PROCEDURE
The back door courtesy switch goes on when back door is opened and goes off when back door is closed.
INSPECTION PROCEDURE
