P0504 Brake Switch "A"/"B" Correlation - Scantool Diagnostics

Monitor GDS Data

1. Connect GDS to Data Link Connector(DLC).
2. Engine start and drive the vehicle on the road.
3. Monitor the "brake switch" parameters on the GDS.








Fig.1) Normal data of Brake Switch on.
Fig.2) Normal data of Brake Switch off.
4. Are the parameters displayed correctly ?
