Remote Control: Service and Repair

Inspection

1. Check the audio remote control switch (A) for resistance between No.5 and No.7 terminals in each switch position.



















Removal

1. Disconnect the negative (-) battery terminal.
2. Remove the driver airbag module.

3. Remove the steering wheel.

4. Remove the steering wheel cover (A) after loosening 6 screws.




5. Remove the remote control switch (B) after loosening 2 screws and disconnecting the connector (A).




[RH]




[LH]






Installation

1. Reassemble the steering wheel remote control switch after connecting the connector.
2. Reassemble the steering wheel.
3. Reassemble the driver airbag module.

NOTE:
Make sure the audio remote control switch and the airbag module connectors are plugged in properly.
